RECIRC | EMPTY | AUTO%u2022 Ideally used in bassboats, flats boats, and other low profile boats for automatic drain control and livewell management%u2022 Accepts mounting of one standard aerator pump for both filling and recirculation%u2022 Includes closed recirculation mode which allows addition of optional pump-out system%u2022 Operates with the MC-1-03-100 actuatorCable Direction Non-PEF PEFQwik-Lok Front MV-13-FN01 MV-13-FP01Rear MV-13-RN01 MV-13-RP01Barbed Front MV-03-FN01 MV-03-FP01Rear MV-03-RN01 MV-03-RP01V3 Actuator MC-1-03-100EMPTY | AUTO%u2022 Ideally used in bassboats, flats boats, and other low profile boats for automatic drain control and livewell management%u2022 Accepts mounting of one standard aerator pump for both filling and recirculation%u2022 Operates with the MC-1-02-100 actuator*PEF or Pressure Equalization Flapper. More info on page 22Cable Direction Non-PEF PEF*Qwik-Lok Front MV-12-FN01 MV-12-FP01Rear MV-12-RN01 MV-12-RP01Barbed Front MV-02-FN01 MV-02-FP01Rear MV-02-RN01 MV-02-RP01V2 Actuator MC-1-02-100V2 TWO-POSITION AUTOMATIC VALVE V3 THREE-POSITION AUTOMATIC VALVE In the EMPTY position of systems V2 & V3, water is allowed to exit the livewell drain, but is not allowed to enter. For system V4, EMPTY allows water to pass in either direction.When on plane, the AUTO position allows water to enter the valve and pump from both outside and from the livewell. When on plane, the outside port is closed to prevent water loss and livewell water continues to enter the valve and pump for recirculation.EMPTY AUTOV2 VALVE POSITIONSIn the RECIRC position, the pump receives water from the livewell only. Outside water is blocked.When on plane, the AUTO position allows water to enter the valve and pump from both outside and from the livewell. When on plane, the outside port is closed to prevent water loss and livewell water continues to enter the valve and pump for recirculation.RECIRCAUTOIn the EMPTY position of systems V2 & V3, water is allowed to exit the livewell drain, but is not allowed to enter. For system V4, EMPTY allows water to pass in either direction.EMPTYV3 VALVE POSITIONS19 %u2022 Valves, Actuators, and CablesTo order product visit www.flow-rite.com or call 616-583-1700
